Warshall’s Algorithm
Warshall’s Algorithm
Warshall’s Algorithm is a neat trick that answers this question for every pair of vertices in a graph.
It creates something called the Transitive Closure, which is basically a giant “Yes/No” table that says:
- 1 → Yes, a path exists
- 0 → No, there is no path
Let’s understand this slowly and comfortably.
🌿 What Warshall’s Algorithm Really Does
Imagine you have a group of cities connected by roads.
You want to know:
“Is there any possible route, even with detours, from City X to City Y?”
Warshall’s Algorithm checks all combinations of:
- starting city i
- ending city j
- a possible middle stop k
And it asks a simple question:
“If I can go from i → k, and from k → j,
does that mean I can go from i → j?”
If the answer is yes, it updates the matrix with 1.
It does this again and again, for every node as the “middle stop” (k).
The final result is the path matrix (transitive closure), which tells you all reachable pairs.
🧠 Understanding the Idea with a Small Example
Let’s take this graph:
A → B → C
↑ ↓
| |
+-------+Connections:
- A → B
- B → C
- C → A
This graph forms a cycle.
Let’s order the vertices as A, B, C.
📘 Step 1: Start with the Adjacency Matrix
Use 1 for direct edges.
A B C
----------
A | 0 1 0
B | 0 0 1
C | 1 0 0📘 Step 2: Apply Warshall’s Algorithm
We allow each vertex (A, B, C) to act as a “middle point” one by one.
Think of it like:
- First, assume paths can go through A
- Then assume paths can go through B
- Finally, assume paths can go through C
As each middle-point becomes allowed, more paths become possible.
After completing all steps, the matrix becomes:
A B C
----------
A | 1 1 1
B | 1 1 1
C | 1 1 1This means:
- You can reach everywhere from everywhere —
exactly what we expect in a cycle.
🎨 Diagram (Simple and Clear)
Original Graph
A → B → C
↑ ↓
+-------+Adjacency Matrix (Initial)
A B C
----------
A | 0 1 0
B | 0 0 1
C | 1 0 0Transitive Closure (After Warshall’s Algorithm)
A B C
----------
A | 1 1 1
B | 1 1 1
C | 1 1 1🌼 How the Algorithm Works (In Plain English)
Warshall doesn’t ask complicated questions.
It simply checks:
If i can reach k, and k can reach j,
then i can also reach j.
It repeats this for every possible choice of k.
Kind of like:
- “Can I visit my friend using this person as a connecting stop?”
If yes → update to 1.
🌟 Analogy: Friends and Introductions
Think of each vertex as a person.
- If A knows B directly → write 1
- If B knows C → write 1
Warshall’s Algorithm then asks:
“If A knows B, and B knows C,
does A indirectly know C?”
Yes → mark 1.
This is exactly how indirect reachability works.
📌 Pseudo-code (Super Simple)
Here’s a gentle version:
for k = 1 to n:
for i = 1 to n:
for j = 1 to n:
if (path[i][j] == 1) OR (path[i][k] == 1 AND path[k][j] == 1):
path[i][j] = 1No need to memorize—it’s the idea that matters.
🎯 Why Warshall’s Algorithm is Useful
- It helps find all reachable nodes in a graph.
- It is used in network routing.
- It helps detect connectivity.
- It is essential in graph theory and algorithms.
Whenever you want a “complete reachability map,” Warshall’s Algorithm is your friend.
