🌐 Parallel Processors (Cache Coherency)

Have you ever shared a document with friends where everyone edits their own copy?
Now imagine one friend changes a sentence, but the others still see the old version. Confusing, right?
That’s exactly what happens in computers when multiple processors (CPUs) work together but don’t keep their data copies in sync.
This problem is known as cache incoherency, and fixing it is what we call cache coherency.

🧠 What’s Going On Here?

In a multiprocessor system, we have several CPUs working at the same time.
Each CPU has its own cache memory, which stores copies of data from the main memory (RAM) to make processing faster.

But here’s the tricky part —
If one processor updates its cached copy of a variable, how will other processors know that the value has changed?
If they still use the old value from their own cache, the system will give incorrect results.

So, cache coherency means keeping all caches consistent — ensuring that every processor sees the most recent value of shared data.

⚙️ Example to Understand It Easily

Imagine three friends — A, B, and C — sharing a grocery list stored in the “main memory.”
Each friend keeps their own copy (their cache) for convenience.

A changes “Buy 1 kg of rice” to “Buy 2 kg of rice.”
But B and C still have the old list showing “1 kg.”

If A doesn’t tell B and C about the change, the shopping trip ends in chaos!
Similarly, in a computer, when one processor updates data, others must be notified so they can update or discard their old cache copies.

💡 Why Cache Coherency Matters

Without cache coherency:

Data becomes inconsistent.
Processors may work on outdated values.
The system produces wrong or unpredictable results.

Maintaining coherency ensures correct communication between all processors and memory.

🔄 How Cache Coherency Is Maintained

There are several techniques to handle cache coherency, but two major approaches are:

1. Snoopy Protocols

All caches “listen” to a shared communication bus.
When one cache updates a value, others snoop the bus and either update or invalidate their own copy.

🗣️ Think of it like friends in a group chat. When one person updates the plan, everyone else instantly gets the message.

2. Directory-Based Protocols

Instead of broadcasting updates to everyone, a directory keeps track of which processor owns which data.
When data changes, the directory notifies only those processors that need the update.

📒 Imagine one friend acting as the “note keeper” who tells only the relevant people when something changes.

🧩 Common Cache Coherency States (MESI Protocol)

One popular way to maintain coherency is the MESI protocol, which tracks data using four states:

State	Meaning
M (Modified)	The cache has updated data not yet written to main memory.
E (Exclusive)	The cache has data identical to main memory, and no other cache has it.
S (Shared)	The data is the same in main memory and may exist in other caches.
I (Invalid)	The data is outdated and should not be used.

These states help processors decide when to read, write, or discard data.

🧭 Simple Diagram of Cache Coherency

          +------------------------+
          |       Main Memory      |
          +------------------------+
                    |     ^
         +----------+     +----------+
         |                         |
 +-----------------+     +-----------------+
 |  Processor 1    |     |  Processor 2    |
 |  +-----------+  |     |  +-----------+  |
 |  | Cache P1  |<-----> |  | Cache P2  |  |
 |  +-----------+  |     |  +-----------+  |
 +-----------------+     +-----------------+
          ↕                         ↕
   Cache Coherency Protocol     (Snoopy/Directory)

In this setup, both processors access shared data through their caches.
The coherency protocol ensures that whenever one cache changes data, others are updated or invalidated to stay consistent.

🏁 In Short

Each processor has its own cache to speed up processing.
When multiple processors share data, inconsistency can occur.
Cache coherency ensures all processors see the same, correct data.
It’s maintained using snoopy or directory-based methods.
Protocols like MESI track data states to avoid confusion.

🌟 Final Thought

You can think of cache coherency like teamwork —
If everyone keeps updating their part without communicating, the project (or program) fails.
But with good coordination and clear updates, the system stays organized, fast, and accurate.
That’s the beauty of cache coherency in parallel processors!
