SNMP (Simple Network Management Protocol) – Port Details for Client and Server

Posted on by

SNMP (Simple Network Management Protocol) is an internet-standard protocol used for managing devices on IP networks, such as routers, switches, servers, and printers. It enables network administrators to monitor and control networked devices, gathering information about their performance, configuration, and status.

SNMP operates over the UDP (User Datagram Protocol) rather than TCP, as it is designed for lightweight communication without the overhead of connection establishment.

SNMP Ports:

SNMP uses two primary ports:

  1. UDP Port 161 – SNMP Client (Manager) Port
    • This port is used by the SNMP Manager (Client) to send requests (GET, SET, etc.) to SNMP agents on network devices.
    • The SNMP Manager is responsible for managing and monitoring network devices, requesting data from the SNMP Agent (running on devices like routers, switches, or servers).
    • It communicates with devices using SNMP requests such as GET, SET, or TRAP to retrieve or configure device parameters.
  2. UDP Port 162 – SNMP Server (Agent) Trap Port
    • This port is used by the SNMP Agent (Server) to send Trap messages to the SNMP Manager.
    • Trap messages are unsolicited alerts sent from the SNMP Agent to the Manager to notify it of significant events or changes in the device’s status (such as a network failure or device malfunction).
    • This port is typically used for asynchronous notifications from devices to the management system.

How SNMP Client and Server Use These Ports:

  1. SNMP Manager (Client):
    • The SNMP Manager (Client) typically runs on a system like a network monitoring tool (e.g., SolarWinds, PRTG, or Nagios).
    • The Manager sends SNMP requests to the Agent (running on networked devices) over UDP Port 161.
    • Requests can include actions like retrieving device status, configuration information, or modifying settings on the device (depending on permissions).
  2. SNMP Agent (Server):
    • The SNMP Agent (Server) is a software component running on network devices (routers, switches, printers, etc.), which provides network monitoring data to the SNMP Manager.
    • The Agent listens on UDP Port 161 for incoming requests and responds with data if applicable.
    • If the device experiences an important event (e.g., an interface goes down or a temperature sensor exceeds a threshold), the SNMP Agent sends an SNMP Trap to the SNMP Manager over UDP Port 162 to notify the manager of the event.
    • The SNMP Trap is sent unsolicited, meaning it is sent without the Manager explicitly requesting it.

Example of Communication Flow:

  1. Manager to Agent (Request):
    • The SNMP Manager sends a GET request to the SNMP Agent on Port 161 to retrieve the value of a specific OID (Object Identifier) like the CPU usage of a device.
    • The SNMP Agent receives the request on Port 161, processes it, and sends the requested data back to the Manager.
  2. Agent to Manager (Trap Notification):
    • If a significant event occurs, the SNMP Agent sends a Trap message to the SNMP Manager on Port 162.
    • For example, if a network interface goes down, the Agent will send a Trap message to Port 162, alerting the Manager.

Security Considerations:

  • SNMPv1 and SNMPv2c are less secure because they transmit community strings in clear text.
  • SNMPv3 provides enhanced security with features such as authentication (e.g., MD5, SHA), encryption (e.g., DES, AES), and access control, ensuring that SNMP messages are securely transmitted over the network.

In Summary:

  • UDP Port 161: Used by the SNMP Manager (Client) to communicate with SNMP Agents (Servers) for requests.
  • UDP Port 162: Used by the SNMP Agent (Server) to send Trap messages to the SNMP Manager (Client).

These ports are essential for facilitating SNMP-based communication between network management systems (clients) and managed network devices (servers or agents).
